ENT

Prima Lite ENT

Clinic-ready optics for the ear, nose and throat.

Prima Lite ENT is an ENT microscope for the office and the procedure room. Its five-step apochromatic changer, 0.4x to 2.5x, gives immaculate optical clarity, and a SuperLux 27 W LED built into the body delivers more than 100,000 lux at 5700 K for the most accurate diagnostic and surgical view. An f250 objective with fine focus and a 90° straight binocular tube suit the ear exam. ProLine accessories add documentation and assistant viewing on day one or later, as the clinic needs them.

OBJECTIVE
f250 mm fine focus
ILLUMINATION
SuperLux 27 W LED
VIEWING HEAD
90° straight binocular tube
VIDEOS

Prima Lite ENT, in motion.

Prima Lite ENT full feature walkthrough1:56
ADVANTAGES

Why Prima Lite ENT.

Prima Lite ENT detail

Versatile from diagnosis to surgery.

Its adaptable optics and fluid arm movement guarantee precision during diagnostic procedures, while surgical tasks become effortless. Adding a camera while maintaining a high degree of balance with zero drift is a cornerstone of the Prima Lite.

Prima Lite ENT detail

Bright and homogenous illumination is delivered thanks to an integrated 27W LED illumination system.

Meticulous attention was paid to the optical coupling design to minimize light-loss internally, and elimination of fiber optics help maintain the integrity of illumination over time. High caliber glass inputs, together with an exacting design standard allow the PRIMA lite to deliver supreme efficiency: 100,000 lux with very low power consumption with a 50,000 hour diode life expectancy. Light is delivered coaxially for shadow-free imaging. With precise color temperature control, anatomy is illuminated true to nature.

Prima Lite ENT detail

Enjoy exceptional visual clarity and eye relief with the LABOMED® PRIMA lite ENT microscope.

Apochromatic optical design comes together with superior coatings to deliver high anti-glare, scratch resistant optics that will stand the test of time. A fluidly adjustable magnification changer will deliver a range of magnification settings that can be adjusted with the help of readily available optical accessories. Plus, MaxLite coated optics deliver more light to where it counts most: your eyes.

CONFIGURATOR

Configure your Prima Lite ENT.

Choose the core build, then tell us what you will use it for. We recommend only the accessories that serve those applications, with the part numbers we need to quote.

01Core build
MOUNTING
OBJECTIVE
02What will you use it for?
YOUR BUILD, LAYER BY LAYER
IMAGINGStandard
EYEPIECESStandard
BINOCULAR HEADStandard
BEAM SPLITTER AND ADAPTERSStandard
OBJECTIVEf=250 mm (included)
ARM AND MOUNTINGFloor stand
BUILD SHEET1 line
Prima Lite ENT
Prima Lite ENT base unitFloor stand, f=250 mm (included)6182504
Included with the base unit
  • 5 step 0.4x to 2.5x, MaxLite optics
  • 27 W LED, 100 to 240 V
  • 90° straight binocular head, IPD 49 to 78 mm
  • f=250 mm CMO with fine focus
  • Dual front handles
  • Yellow and green filters
REQUEST A QUOTE FOR THIS BUILD

Part numbers from the LABOMED® product catalog. Labo America confirms compatibility and pricing.

SPECIFICATIONS

Full specifications

Taken from the current Prima Lite ENT product record. Confirm configuration specific values with Labo America.

MicroscopeApochromatic 5 step: 0.4x, 0.6x, 1.0x, 1.6x and 2.5x, MaxLite coated optics
IPD Range49 to 78 mm
Accessories (Optional)ProLine video accessories including Smartphone Adapter; DSLR adapters for Canon, Nikon, and Sony; C-mount adapters for 1/2" and 1/3" sensor cmos cameras; Assistant viewer bridge (assistoscope); ergonomic enhancements for surgical use; universal endoscope adapter; dual beam splitters (flat and inclined); single port rear facing beam splitter
ObjectiveStandard: f250 mm fine focus. Optional: f300 mm fine focus, f400 mm fine focus, NuVar 7 (f290 to 360 mm, working distance 200 to 270 mm)
EyepieceStandard: WF 10x/18 mm with lockable eye guards Optional: WF 12.5x/18 mm with lockable eye guards
Diopter AdjustmentBoth eyepieces, lockable
IlluminationSuperLux 27 W LED, integrated in microscope housing, 100V to 240V universal power supply
FiltersGreen and Yellow
Microscope carriers120° carrier
Viewing Body90° straight binocular tube
DIMENSIONS

The Prima Lite ENT, measured.

Dimensional drawings for planning the bench, cart or operatory. All dimensions in millimeters (mm).
