eVO 300 Microscope

Efficient Microscope Design for a Streamlined Office

The eVO 300 delivers a streamlined design with high precision apochromatic optics for accurate anatomical observations, corrected for spherical and chromatic aberrations to ensure comfortable and reliable use. Eco-friendly illumination options, lead-free high dispersion glass, paints and materials minimize the system's environmental impact without sacrificing performance and durability. The eVO 300 represents all that a slit lamp should be.
Labomed eVO 300 Microscope

eVO 300 Advantages:

Labomed eVO 300 Cross Section

An apochromatic optical design ensures crisp, strain-free images with superior color fidelity and contrast. The eVO™ series of slit lamps is part of a new generation of our proprietary MaxLite™ coated optics, with the latest advancements in anti-reflective and scratch resistant surface technology for a more pristine image over time.

Labomed eVO 300 Microscope Adapters

A built-in photo port makes documentation simpler and more affordable. Adapters are available for most digital and analog cameras, all while maintaining the system's streamlined form factor. For convenience in fluorescein exams, the microscope has a flip-in Wrattan filter built into the optical chamber.

Labomed eVO 300 Microscope Illumination

Efficient and compact illumination design translates to a bright and evenly illuminated image at all magnifications. Halogen and cool LED options are available within a compact bulb housing.

The eVO 300 is not currently available for sale in North America.

Microscope Specifications

  • Microscope

    Galilean

  • Magnification

    5 step: 6.5X, 10X, 16X, 25X, 40X

  • Eyepiece

    WF 12.5X/18mm, diopter adj. ± 5mm

  • IPD Range

    48.5 - 77mm

  • Slit Length/Width

    0 - 13.5mm

  • Slit Apertures

    0.6, 5.8, 9, 13.5mm and continuous 1.5 to 12.0mm

  • Slit Rotation

    0 - 180°

  • Slit Tilt

    ---

  • Filters

    Red free, Cobalt blue, Heat absorbing

  • Weight

    Microscope with carrier - 2.8kg Swivel arm - 8kg Base with pillar - 30kg

Movement Ranges:

  • Longitudinal (in/out)

    100mm

  • Lateral (left/right)

    107mm

  • Vertical (up/down)

    30mm

  • Chin Rest Range

    80mm

  • -

  • Illumination

    Halogen 6V-20W

  • Table Base Size

    465mm X 316mm

  • Weight

    25kg (packed)

  • Voltage

    100-240V AC

  • Frequency

    50-60 Hz

Accessories (Optional)

  • Tonometer, Beam splitter, Cameras, Diffuser, Motorized table

Dimensions (mm)

Prima eVO 300 Microscope Line Drawing

Configurations

Prima eVO Microscope System Drawing

Downloads

Labomed eVO 300 Brochure

eVO 300 Brochure

Learn more about the eVO's unique value offering.
Download
Labomed eVO 300 Microscope User Manual

eVO 300 User Manual

Learn all about the eVO 300, its functions, and more.
Download English
Download Spanish
