eVA

Gynecology eVA MICROSCOPE

OB/GYNs should be equipped with the best tools to make diagnostic assessments simpler and more accurate. Brilliant optics in the eVA colposcope reveal the most subtle lesions or atypical vascular patterns and provide improved control over biopsies, with sharp details extending all the way to the peripheral margins.

Doctors are further supported by unique features such as an ergonomic control cluster, vertical height adjustment with EZLift, and an onboard 50W LED illuminator for bright, white, and unwavering light.

ADVANTAGES OF eVA

eVA Colposcope Advantages

A 50W super bright LED provides lux outputs comparable to Xenon light, but runs cooler and delivers 60,000 hours of bulb life. Operating with a color temperature comparable to daylight, the system ensures bias-free diagnosis.

eVA Colposcope Advantages

An Apochromatic Galilean optical system produces sharp contrast and resolution at every step. Proprietary MaxLite™ sputtered coatings promise the highest degree of anti-reflective and anti-scratch properties, yielding artifact free and durable optics.

eVA Colposcope Advantages

The eVA colposcope flattens the learning curve with an ergonomic control cluster, including filter change, fine focus and joystick, all positioned at your fingertips. The EZLift z-axis option allows smooth adjustment of the viewing tube height for an ideal viewing posture.

  • Light Source

    50 W eVALUX LED; lamp life of up to 60,000 hours

  • Built-in-Filters

    Green & Yellow

  • Binocular Tube

    Straight, IPD 50 Straight, IPD 50-75 mm optional: 45 ° inclined -75 mm optional: 45 ° inclined

  • Objective

    f-300 mm, High contrast aperture optional: f-400 mm

  • Microscope carriers

    Straight carrier, X-Y and inclination

  • Apochromatic Magnichanger

    5 step: 0.4X, 0.6X, 1.0X, 1.6X, 2.5X

  • Stand

    Star base stand, lockable wheels

  • Optional Accessories

    Camera, Beam splitter, Monitor arm

  • Stative

    Stand with star-shaped base, lockable wheels

  • Ocular

    WF 10X / 18mm focusable with eye shields, retractable, ± 5mm diopter adjustment with diopter lock; Optional: WF 12.5X / 18 mm

  • Accessories (Optional)
    • ProLine accessories and camera adapters
Mounting

Configurations

eVA Colposcope User Manual

eVA Colposcope User Manual

Learn all about the eVA Colposcope, its functions, and more.

eVA Colposcope Brochure

eVA Colposcope Brochure

Learn more about the eVA's unique value offering.
